CAJIXXXXXX PH Electrode for Effluent/Groundwater/Pharma/Chemical/Petroleum Applications

CAJIXXXXXX PH Electrode for Effluent/Groundwater/Pharma/Chemical/Petroleum Applications. Spherical membrane, up to 6 bars pressu

TOSCHON-3298

Introducing the CAJIXXXXXX pH electrode from ÉQUIPEMENT SCIENTIFIQUE TOSCHON. This electrode is perfect for EFFLUENT / GROUNDWATER / PHARMA / CHEMICAL / PETROLEUM APPLICATIONS, with a pH range of 0-12/0-14 and pressure resistance up to 6 bars at 25°C. The electrode features a borosilicate shaft, Teflon diaphragm, and optional built-in Pt100/Pt1000 sensors for temperature compensation. The reference system is SREF+ (Single Junction) or Ag/Ag Wire (Double Junction) with HGel+ filling solution or gel. The low noise coaxial cable comes with a Cap/TC* connector and BNC connector, or any other connector requested.

Hurry up! Only 500 still articles in stock.
Quantity

ÉQUIPEMENT SCIENTIFIQUE TOSCHON

Sonde ph toschon - CAJIXXXXXX

The Toschon pH electrode is a high-quality electrode designed for use in a variety of applications. It is suitable for use in effluent, groundwater, pharmaceutical, chemical, and petroleum applications. The electrode has a pH range of 0-12/0-14 and an operating temperature range of 0 to 100ºC. It can withstand pressures of up to 6 bars at 25°C.

Features:

  • Type of electrode: PH electrodes
  • Key designation: EFFLUENT / GROUNDWATER / PHARMA / CHEMICAL / PETROLEUM APPLICATION
  • Shaft Material: Borosilicate
  • Membrane glass
  • Shaft Length (mm): 120
  • Diameter (mm): 12
  • Diaphragm: Teflon, Additional Ceramic (in case of Double Junction)
  • Number Junction Junction: Single / double
  • Membrane shape: spherical
  • Temperature compensation: Optional:built-in Pt100 / Pt 1000 sensors
  • Reference system: SREF+ (Single Junction) or Ag/ Ag Wire (Double Junction)
  • Reference electrolyte (illing solution or Gel): HGel+
  • Cable: Low noise Coaxial cable
  • Connector Type: Cap/TC* with BNC with Low-Noise Coaxial Cable or S7 or S8 or Variopin or any other connector requested
: TOSCHON-3298
