CAJ PH Electrode for General Use Applications - Toschon Scientific Equipment

Toschon CAJ PH Electrode for General Use Applications

TOSCHON-3297

Introducing the CAJ PH electrode from ÉQUIPEMENT SCIENTIFIQUE TOSCHON. This general use electrode is perfect for scientific applications with a PH range of 0-14 and operating temperature range of 0 to 80°C. With a shaft length of 120mm and diameter of 12mm, it features a ceramic diaphragm and a single junction. The electrode is made of glass and has a spherical membrane shape. It can withstand pressures up to 6 bars at 25°C and has a reference system of Ag/Agcl with a gel reference electrolyte. The low noise coaxial cable is available in various lengths and connector types including BNC.

Hurry up! Only 500 still articles in stock.
Quantity

ÉQUIPEMENT SCIENTIFIQUE TOSCHON - Sonde ph toschon (Model: CAJ)

The Sonde ph toschon is a high-quality pH electrode designed for general use applications in scientific equipment. It has a pH range of 0-14 and can operate in temperatures ranging from 0 to 80 °C. With a pressure resistance of up to 6 bars at 25 °C, it is suitable for use in a variety of environments. The shaft of the electrode is made of glass and is 120 mm long with a diameter of 12 mm. The diaphragm is made of ceramic and the membrane is spherical in shape.

The Sonde ph toschon features a single junction and a reference system of Ag/Agcl. The reference electrolyte is a gel and the electrode is connected to the scientific equipment via a low noise coaxial cable with a BNC or other connector type. The electrode does not have temperature compensation.

Features:

  • Type of electrode: PH electrodes
  • Key designation: General use applications
  • Operating Temperature range: 0 to 80 °C
  • PH range: 0 - 14
  • Pressure: up to 6 bars at 25 °C
  • Shaft Material: Glass
  • Membrane glass
  • Shaft Length (mm): 120
  • Diameter (mm): 12
  • Diaphragm: Ceramic
  • Number Junction Junction: Single
  • Membrane shape: Spherical
  • Temperature compensation: No
  • Reference system: Ag/Agcl
  • Reference electrolyte (filling solution or Gel): Gel
  • Cable: Low noise Coaxial cable
  • Connector Type: BNC or other connectors
: TOSCHON-3297
