TOCHON CAM XX PH Electrode for Micro Volumes, 0-14 pH Range

Micro volumes PH electrode CAM XX by Toschon for scientific equipment.

TOSCHON-3296

Introducing the CAM XX PH electrode from ÉQUIPEMENT SCIENTIFIQUE TOSCHON. Designed for micro volumes, this electrode has a pH range of 0-14 and can operate in temperatures ranging from 0 to 100°C. The shaft is made of glass and is 120mm long with a diameter of 3mm (on 60mm). It features a single junction and a spherical membrane shape. The reference system is SREF + and the reference electrolyte is 3M KCL. The electrode comes with a low noise coaxial cable and a cap with BNC connector, or any other connector required.

Hurry up! Only 500 still articles in stock.
Quantity

ÉQUIPEMENT SCIENTIFIQUE TOSCHON - Sonde ph toschon (CAM XX)

This PH electrode is designed for micro volumes and is ideal for scientific equipment applications. The electrode is made with glass shaft material and has a ceramic diaphragm. The spherical membrane shape is designed for single junction use and has a reference system of SREF+. The reference electrolyte used is 3 M KCL. The operating temperature range is 0 to 100 °C and the PH range is 0 - 14. The electrode has a shaft length of 120 mm and a diameter of 3 mm (on 60 mm). The cable is a low noise coaxial cable with a cap and BNC connector. Temperature compensation is not available with this electrode.

Features:

  • PH electrode for micro volumes
  • Type of electrode: PH electrodes
  • Operating Temperature range: 0 to 100 °C
  • PH range: 0 - 14
  • Shaft Material: Glass
  • Membrane glass
  • Shaft Length (mm): 120
  • Diameter (mm): 3 (on 60 mm)
  • Diaphragm: Ceramic
  • Number Junction Junction: Single
  • Membrane shape: Spherical
  • Temperature compensation: No
  • Reference system: SREF +
  • Reference electrolyte (filling solution or Gel): 3 M KCL
  • Cable: Low noise Coaxial cable
  • Connector Type: Cap with BNC with Low-Noise Coaxial Cable or S7 or any other connector required

This PH electrode is a reliable and accurate tool for scientific equipment applications. Its design and features make it ideal for micro volume measurements and its low noise coaxial cable ensures that the readings are precise and accurate.

: TOSCHON-3296
Hurry up! Only 500 still articles in stock.
