    TOCHSON CASM XX PH electrode for small volumes (0.2 ml)

    5 1
    TOSCHON-3295

    Introducing the CASM XX pH electrode from ÉQUIPEMENT SCIENTIFIQUE TOSCHON. Designed for small volumes (0.2 ml) and with a glass shaft material, this electrode has a spherical membrane shape and a single junction. It has a pH range of 0-14 and an operating temperature range of 0-70°C. The electrode comes with a low noise coaxial cable and a cap with BNC connector or S7 connector, and uses a 3M KCL reference electrolyte.

    Quantity

      Free 96 hour delivery

    For all order over €54.00



    Secure card payment

      Quality probes

    Made in europe

      Technical support

    Experts at your service

      Compatible or reimbursed

    Our engagement

    Description

    Product Description

    The CASM XX is a pH electrode designed for small volume measurements, with a shaft length of 120mm and a diameter of 6mm on 40mm. It is part of the ÉQUIPEMENT SCIENTIFIQUE TOSCHON product line and is suitable for scientific applications.

    The electrode has a green membrane glass and a ceramic diaphragm with a spherical membrane shape. It operates within a temperature range of 0 to 70°C and can measure pH levels from 0 to 14. The CASM XX electrode uses a single junction and has a reference system of SREF +. The reference electrolyte used is 3M KCL and there is no temperature compensation.

    The electrode comes with a low noise coaxial cable and a cap with a BNC connector. The cable length can be customized to meet the user's needs. The CASM XX electrode is a reliable and accurate tool for pH measurements in small volumes.

    Features

    • Category Parent: ÉQUIPEMENT SCIENTIFIQUE TOSCHON
    • Category Name: Sonde ph toschon
    • Model: CASM XX
    • Type of electrode: PH electrodes
    • Key designation: Small volumes (0,2 ml )
    • Operating Temperature range: 0 to 70 °C
    • PH range: 0 - 14
    • Pressure: N/A
    • Shaft Material: Glass
    • Membrane glass: Green
    • Shaft Length (mm): 120
    • Diameter (mm): 6 (on 40 mm)
    • Diaphragm: Ceramic
    • Number Junction Junction: Single
    • Membrane shape: Spherical
    • Temperature compensation: No
    • Reference system: SREF +
    • Reference electrolyte (filling solution or Gel): 3 M KCL
    • Cable: Low noise Coaxial cable
    • Cable length: Customizable
    • Connector Type: Cap with BNC with Low-Noise Coaxial Cable or S7 or any other connector required
    Product Details
    TOSCHON-3295
