TOCHSON CASM XX PH electrode for small volumes (0.2 ml)

Product Description

The CASM XX is a pH electrode designed for small volume measurements, with a shaft length of 120mm and a diameter of 6mm on 40mm. It is part of the ÉQUIPEMENT SCIENTIFIQUE TOSCHON product line and is suitable for scientific applications.

The electrode has a green membrane glass and a ceramic diaphragm with a spherical membrane shape. It operates within a temperature range of 0 to 70°C and can measure pH levels from 0 to 14. The CASM XX electrode uses a single junction and has a reference system of SREF +. The reference electrolyte used is 3M KCL and there is no temperature compensation.

The electrode comes with a low noise coaxial cable and a cap with a BNC connector. The cable length can be customized to meet the user's needs. The CASM XX electrode is a reliable and accurate tool for pH measurements in small volumes.

Features

• Category Parent: ÉQUIPEMENT SCIENTIFIQUE TOSCHON
• Category Name: Sonde ph toschon
• Model: CASM XX
• Type of electrode: PH electrodes
• Key designation: Small volumes (0,2 ml )
• Operating Temperature range: 0 to 70 °C
• PH range: 0 - 14
• Pressure: N/A
• Shaft Material: Glass
• Membrane glass: Green
• Shaft Length (mm): 120
• Diameter (mm): 6 (on 40 mm)
• Diaphragm: Ceramic
• Number Junction Junction: Single
• Membrane shape: Spherical
• Temperature compensation: No
• Reference system: SREF +
• Reference electrolyte (filling solution or Gel): 3 M KCL
• Cable: Low noise Coaxial cable
• Cable length: Customizable
• Connector Type: Cap with BNC with Low-Noise Coaxial Cable or S7 or any other connector required
