ÉQUIPEMENT SCIENTIFIQUE TOSCHON CAF T PH Electrode for Low & High pH Applications

Toschon CAF T PH Electrode for Low & High pH Applications

TOSCHON-3291

Introducing the CAF T PH electrode from ÉQUIPEMENT SCIENTIFIQUE TOSCHON. Designed for low and high pH applications, this electrode has a pH range of 0-14 and can withstand pressures up to 6 bars at 25°C. The electrode features a glass shaft, ceramic diaphragm, and a spherical membrane shape. It also includes temperature compensation with built-in Pt100/Pt1000 and a reference system with SREF+. The electrode comes with a low noise coaxial cable and can be connected with BNC or other connectors.

Hurry up! Only 500 still articles in stock.
Quantity

ÉQUIPEMENT SCIENTIFIQUE TOSCHON - Sonde ph toschon (CAF T)

The Sonde ph toschon (CAF T) is a high-quality pH electrode designed for low and high pH applications. It is ideal for use in scientific laboratories, research centers, and other settings where accurate pH measurements are essential.

The electrode features a glass shaft that is 120mm long and 12mm in diameter. It has a ceramic diaphragm and a single junction membrane that is spherical in shape. The pH range of the electrode is 0-14, and it can withstand pressures of up to 6 bars at 25°C.

The Sonde ph toschon (CAF T) also comes equipped with a built-in Pt100/Pt1000 temperature compensation system, which ensures accurate readings even in fluctuating temperatures. The reference system is SREF +, and the reference electrolyte used is KCL. The electrode is connected to a low noise coaxial cable, which can be customized to the desired length. The connector type is BNC, but other connectors are also available.

Features:

  • Type of electrode: PH electrodes
  • Key designation: Low & High pH applications
  • Operating Temperature range: 0 to 70 °C
  • PH range: 0 - 14
  • Pressure: up to 6 bars at 25 °C
  • Shaft Material: Glass
  • Membrane glass
  • Shaft Length (mm): 120
  • Diameter (mm): 12
  • Diaphragm: ceramic
  • Number Junction Junction: single
  • Membrane shape: spherical
  • Temperature compensation: Pt100 / Pt 1000 in built
  • Reference system: SREF +
  • Reference electrolyte ( filling solution or Gel): KCL
  • Cable: Low noise Coaxial cable
  • Connector Type: BNC or other connectors
: TOSCHON-3291
