CS150 Conductivity Sensor by Online Sensors | 12mm Graphite Contact for Liquid Measurement - Sensorex Catalog

CS150 - Graphite Contacting Conductivity Sensor, 12 mm

Sonde pH redOx
SENS2-2345
Used for Laboratory and Light Industrial Applications: Cell constants are made from graphite to provide good performance for the value. Configurable to Meet Your Exact Needs:
  • Select from our options below for a quick delivery or fill out the contact us form at the bottom for a custom product!
  • Choose your cell constant, temperature compensation, cable lengths, and connectors
Multiple Use Cases
  • Submerge in a tank or mount in-line in a pipe.
  • Compatible with Sensorex's CM1000 and most portable/bench-top meters
Hurry up! Only 500 still articles in stock.
Quantity

Used for Laboratory and Light Industrial Applications: Cells are made from graphite to provide good performance for the value. Choose from 2 cell constants: 0.1/cm and 1.0/cm The sensor can be configured to meet your exact needs. Select from our available options for a quick delivery or fill out the contact us form at the bottom for a custom product! Customize your cell constant, temperature compensation, cable lengths, and connectors. The sensor can be submerged in a tank or mount in-line in a pipe. CA Residents: Prop 65 WARNING(S)
: SENS2-2345
Hurry up! Only 500 still articles in stock.

Data sheet

Cable Length
BB - 3 Foot Cable (1 meter)\, Standard 4 Wire Cable, BC - 10 Foot Cable (3 meters)\, Standard 4 Wire Cable, BD - 20 Foot Cable (6 meters)\, Standard 4 Wire Cable, BE - 33 Foot Cable (10 meters)\, Standard 4 Wire Cable
Temperature Compensation
1 - PT1000 RTD, 2 - PT100 RTD, M - Custom Modification (10K NTC)
Cell Constant
B - 0.1/cm, C - 1.0/cm
Cable Termination Connector
2 - BNC Connector, 3 - Tinned Leads
Installation/Fitting Type
N - No Selection, 1 - 1/2" NPT Polypropylene, 4 - 3/4" NPT Polypropylene
